| Maximum Conductor Size | Cable 1.18" (30mm), bus bar 2.48x0.19” (63 x 5mm), dual cable 0.98” (25mm) |
| Current Range | 500AAC |
| Measurement Range | 2 to 500AAC |
| Output Signal | 1mVDC / AAC (0.5VDC @ 500AAC) |
| Transformation Ratio | 1000:1 |
| Output | Double insulated 5ft (1.5m) lead with safety 4mm banana plug |
| Accuracy 50/60Hz | 1% @ 500A |
| Frequency Range | 48Hz to 1KHz |
| Phase Shift | N/A |
| Load Impedance | ≥100kΩ |
| Overload | 700A for 10 min |
| Operating Temperature | -5° to +122°F (-15° to +50°C) |
| Storage Temperature | -40° to +185°F (-40° to +85°C) |
| Dimensions | 2.6 x 7.68 x 1.34” (66 x 195 x 34mm) |
| Weight | 14.82 oz (420g) |
| Pollution Degree | 2 |
| Rating | UL 94 V0 |
| Ingress Protection | IP 20 |
| EMC | EN 50081-1 Class B, EN 50082-2, IEC 1000-4-2 |
| Safety Compliance | EN 61010-2-32, 600V CAT III, 300V CAT IV |
