| Maximum Conductor Size | 1.02" (26mm) |
| Current Range | 100AAC/DC |
| Measurement Range | 0.5A to 100AAC/DC |
| Output | 10mV/A |
| Lead Length | 6.5ft (1.9m) |
| Output Termination | BNC connector |
| Accuracy (Typical) | 0.5 to 64A: ±1.15% ±0.1mV 64 to 90A: ±4% 90 to 100Arms: ±5% |
| Phase Shift at 50Hz | ±1° |
| Bandwidth with Filter | 1MHz @ -3dB, 30kHz @ -3dB, 3kHz @ -3dB |
| Frequency Limitation | 100Arms at 45kHz continuously |
| Power Source | 1.2V NIMH AAA rechargeable or 5Vdc power adaptor by female type B micro USB |
| Battery Life | 7 to 8 hours continuous use |
| Compatibility | Any oscilloscopes with BNC input |
| Dimensions (H x W x D) | 5.43 x 1.93 x 1.1” (138 x 49 x 28mm) |
| Weight | 7.04 oz (200g) |
| Operating Temperature | 14° to +122°F (-10° to +55°C); 10 to 85% RH |
| Storage Temperature with Battery | -4° to +122°F (-20° to +50°C); 10 to 85% RH |
| Pollution Degree | 2 |
| Protection | IK 04, IP40 (jaws closed), IP30 (jaws open) |
| EMC | EN 61326-1 |
| Safety Compliance | EN 61010-2-032, 300V CAT III |
