| Channels | Four | |
| Input | Captive AmpFlex® AC current flexible sensors | |
| Ranges (2) | 300AAC | 3000AAC |
| Accuracy (50/60Hz) | 5 to 300A ± (1% Rdg +0.5A) | 15 to 3000A (1% Rdg +1A) |
| Resolution | 0.1AAC | 0.5AAC |
| Sample Rate | 64 samples / cycle | |
| Storage Rate | Programmable from 125ms to 1 per day | |
| Storage Modes | Start/Stop, FIFO, extended mode (XRM) and Alarm | |
| Recording Length | 15 minutes to 8 weeks, programmable using DataView | |
| Memory | 1,000,000 measurements (2MB). Recorded data is stored in non-volatile memory and will be retained even if battery is low or removed. | |
| Communication | Bluetooth (class 2 ) | |
| Power Source | 4x1.5V C alkaline batteries | |
| Battery Life | >200 hours at 125ms up to to >180 days (depending of sample rate/recording length) | |
| Dimensions | 5.9 x 5.9 x 3.57” (150 x 150 x 91mm) | |
| Weight (With Battery) | 3.9 lbs (1.77kg) | |
| Case | UL94-V0 / Case UL94-5VB | |
| Operating Temperature | 14° to 122°F (-10° to 50°C) | |
| Storage Temperature | -4° to 140°F (-20° to 60°C) | |
| Relative Humidity | Up to 85% @ 95°F (35°C) non condensing | |
| Ingress Protection (IP) | IP65 (Cover closed) | |
| EMC | EN 61326-1 | |
| Safety Compliance | IEC 61010-1, EN 61010-2-32 600V CAT IV; Pollution Degree 2 |
|
