| Working principle | cutting |
| Optimal for material type | medium-hard, soft, fibrous samples |
| Cutting tools | rotor with straight cutting edges and fixed knives |
| Materials of the cutting tools | tool steel, stainless steel 316L, chromium-free tool steel, chromium-free steel DC01 |
| Max. feed size (depending on the material and funnel) | 70 x 70 mm |
| Max. throughput (depending on the material and sieve size) | 50 l/h |
| Final fineness (depends on sieve insert - additional sieve sizes available) | 0.25 - 20 mm |
| Feeding | batchwise/continuous |
| Rotor speed | 2800/3400 rpm* |
| Rotor peripheral speed | 14.92/17.9 m/s* |
| Drive | Up to 2.1 kW three-phase motor or single phase motor |
| Electrical Details/torque | 400 V/3~, 50 Hz, 1790 watt, 5.5 Nm |
| Emission sound pressure level at the workplace according to DIN EN ISO 3746 (depending on the material to be ground, rotor and sieve insert used) | LpAd = 78 dB |
| Weight | 32 kg |
| Dimensions (W x D x H) | table-mounting or on stand 42 x 48 x 69 cm |
| *depending voltage and frequency |
