| Working principle | pressure |
| Optimal for material type | very hard, hard, medium-hard, brittle and abrasive samples and for metal-free grinding |
| Grinding tools | fixed and movable crushing jaws |
| Materials of the grinding tools | hardened steel, stainless steel, chromium-free tool steel, manganese steel, hardmetal tungsten carbide, zirconium oxide |
| Max. feed size (depending on material) | 95 mm |
| Min. sample quantity | 20 ml |
| Max. continuous throughput (depends on material and gap width) | 250 kg/h |
| Final fineness | 0.3 - 15 mm |
| Feeding | batchwise/continuous |
| Eccentric oscillations | 308 movements/min |
| Electrical Details*(other voltages available on request) | 400 V/3~, 50/60 Hz, 3490 Watt |
| Instrument also available in the following voltage | 200 V/3~, 50/60 Hz, 3490 Watt - order no. 01.2040.00 |
| Emission sound pressure level at the workplace according to DIN EN ISO 3746 (depending on the material to be crushed) | approx. LpAd = 83 dB |
| Weight | 320 kg |
| Dimensions (W x D x H) | bench top instrument 55 x 90 x 106 cm |
