Specifications
| Item Code | 212899 |
|---|---|
| Model | DKG811V |
| Method | Forced convection |
| Operating temperature range | Room temp. +30°C to 260°C |
| Temperature adjustment accuracy | ±0.5℃ |
| Temperature distribution accuracy | ±2℃（at 200℃）、±2.5℃（at 260℃） |
| Time to attain max. temp. | Within 50min. from 25°C ->260°C |
| Temp. decrease time | About 50min. from 260°C ->50°C |
| Air supply/exhaust damper | Main body front operation / manual damper Air supply pipe / exhaust pipe back NSSC180 with exhaust duct |
| Interior/exterior | Stainless steel plate/Electrogalvanized steel sheet baking paint |
| Heater and heat insulator | SUS pipe heater |
| Heater capacity | 200 to 220V 3.6 to 4.36kW |
| Blower fan | 2 sirocco fans |
| Fan motor | Condenser type motor |
| Cable port | I.D.: 30mm at the right side of the main body x 1 |
| Door packing | Fluororubber |
| Air supply port | Heater chamber bottom (opening and closing with manual damper) |
| Damper control | Air supply / exhaust interlocking with the manual operation knob on the front of the main unit |
| Exhaust port | Upper part of rear of the main body: φ80 (Open / Close with a manual damper) |
| Heater control | SSR control |
| Sensor | K thermocouple (for temperature control / independent overheating protector) |
| Safety unit | Operation Features : Fixed value operation, program operation, quick auto stop, auto stop, auto start, program auto start |
| Safety unit | Program mode : 6 patterns (program 1:30 step, program 2-3: 15 step, program 4-6: 10 step) step weight function, repeat function, step hold function, step skip function |
| Internal dimensions（W×D×H mm） | 600×500×1000mm |
| External dimensions（W×D×H mm） | 770×696×1674mm |
| Withstand load of shelf | 15 kg / pc. |
| Shelf support step number | 15 steps |
| Shelf support pitch | 60mm |
| Accessories Shelf | 4 pcs. |
| Accessories Shelf support | 8 pcs. |
| Power Source | Single Phase AC200 to AC220V 18.5-20.5A Breaker capacity and power supply equipment capacity 30A. Power plug is not included. The length of the power cord is about 2m. |
| Weight | 155kg |
| Remarks(dimensions) | 300L |
‘
‘
‘
