The BD Avantgarde.Line series is specially designed for gentle incubation of organisms, as well as conditioning of heat-sensitive media. The new design of the units and the homogeneous temperature distribution ensure the very best results.
+5°C above ambient temperature to +100°C
| Designation | BD260-230V | BD260UL-120V |
| Article Number | 9010-0329 | 9010-0330 |
| Option model | Standard | Standard |
| Designation | BD260-230V | BD260UL-120V |
| Temperature range | +5 °C above ambient temperature to 100 °C | +5 °C above ambient temperature to 100 °C |
| Temperature uniformity at 100°C | 1.0 ± K | 1.0 ± K |
| Temperature uniformity at 37°C | 0.3 ± K | 0.3 ± K |
| Temperature fluctuation at 100°C | 0.5 ± K | 0.5 ± K |
| Temperature fluctuation at 37°C | 0.2 ± K | 0.2 ± K |
| Heating up time to 100°C | 75 min | 75 min |
| Heating up time to 37°C | 60 min | 60 min |
| Recovery time after door was opened for 30 s at 37°C | 16 min | 16 min |
| Designation | BD260-230V | BD260UL-120V |
| Rated Voltage | 230 V | 120 V |
| Power frequency | 50/60 Hz | 60 Hz |
| Nominal power | 0,85 kW | 0,95 kW |
| Unit fuse | 8,0 A | 12,5 A |
| Phase (Nominal voltage) | 1~ | 1~ |
| Designation | BD260-230V | BD260UL-120V |
| Interior volume | 253 L | 253 L |
| Net weight of the unit (empty) | 85 kg | 85 kg |
| Load per rack | 40 kg | 40 kg |
| Permitted load | 270 kg | 270 kg |
| Wall clearance back | 160 mm | 160 mm |
| Wall clearance sidewise | 100 mm | 100 mm |
| Designation | BD260-230V | BD260UL-120V |
| Width net | 810 mm | 810 mm |
| Height net | 940 mm | 940 mm |
| Depth net | 760 mm | 760 mm |
| Designation | BD260-230V | BD260UL-120V |
| Interior width | 610 mm | 610 mm |
| Interior height | 760 mm | 760 mm |
| Interior depth | 545 mm | 545 mm |
| Inner doors | 1 | 1 |
| Unit doors | 1 | 1 |
| Designation | BD260-230V | BD260UL-120V |
| Energy consumption at 100°C | 225 Wh/h | 225 Wh/h |
| Energy consumption at 37°C | 40 Wh/h | 40 Wh/h |
| Designation | BD260-230V | BD260UL-120V |
| Number of shelves (std./max.) | 2/8 | 2/8 |
