The 5" LCD touchscreen enables easy operation of the paint viscosity tester. The measured values from the viscometer are displayed during the measurement. At the same time, the measured values are graphically displayed on the viscometer in order to obtain a course of the viscosity.
The external temperature sensor on the paint viscosity tester can be used to ensure that the sample is at the correct temperature. This allows the measurement results to be compared with other samples, since the temperature has an influence on the viscosity. Thus, the temperature measurement is an essential part of the determination of the viscosity.
With the optional software, the paint viscosity tester can be connected to a PC. The software displays the measured values from the viscometer live during a measurement. The individual measuring points are displayed in a table as well as graphically. The recorded measured values can be exported as a .csv file for further processing.
| Viscosity | |
| Measuring range | 40.2 ... 141 KU |
| 27 ... 5250 cp (1cP = 1 mPa*s) | |
| 32 ... 1099 g | |
| Resolution | 0.1 KU |
| 1 cp | |
| 1 g | |
| Accuracy | ±1 % of full scale |
| Temperature | |
| Measuring range | -20 ... 250 °C / -4 ... 482 °F |
| Resolution | 0.1 °C |
| Accuracy | ±0.3 °C |
| Spindle | KU1 |
| Rotation speed | 200 RPM |
| Measuring cup volume | 600 ml |
| Display | 5" LCD touchscreen |
| Power supply | primary: 100 ... 240 V AC, 0.5 A |
| secondary: 12V DC, 2 A | |
| Operating conditions | 5 ... 35 °C / 41 ... 95 °F, (20 °C / 68 °F recommended temperature) |
| <80 % non-condensing | |
| Dimensions | 420 x 180 x 300 mm / 16.5 x 7.1 x 11.8" |
| Weight | ca. 5 kg / 11 lb |
