Wireless, CAN/CAN FD input only
| Connectable instrument | Memory HiLogger LR8450-01 (Wireless LAN model) | |||||
|---|---|---|---|---|---|---|
| Control communications method | Connect wirelessly via Wireless LAN Adapter Z3230 (included) Wireless LAN (IEEE 802.11b/g/n) Communication range: 30 m (line of sight) Encryption function: WPA-PSK/WPA2-PSK, TKIP/AES Available number of channels: 1 to 11 |
|||||
| Communications buffer memory | 4 M word (volatile memory) Saves data in the event of a communications error. Data is resent when communications are restored. |
|||||
| Operating temperature and humidity |
-20°C to 55°C, 80% RH (no condensation) (Charging temperature range: 5°C to 35°C) |
|||||
| Storage temperature and humidity |
-20°C to 60°C, 80% RH (no condensation) | |||||
| Vibration resistance | JIS D 1601:1995 5.3(1), Class 1A (passenger vehicle) equivalent | |||||
| LED display | Wireless connection, measurement status, error status, AC adapter/external power, battery power, charge status, CAN bus communication status, termination resistor connection status | |||||
| Automatic connection function | Available | |||||
| Included accessories | Wireless LAN Adapter Z3230 × 1, Instruction manual × 1, AC Adapter Z1008 × 1, mounting plate × 1, M3×4 screw × 2 (for use with mounting plate) | |||||
| Number of input channels |
Max. 500 channels (max. 500 signals) , depends on data refresh interval | |||||
| Input terminals | D-sub 9 pin MALE × 2 | |||||
| Protocols supported | CAN (ISO11898) CAN FD (ISO11898) CAN FD (non-ISO) |
|||||
| Physical layer | ISO11898 (High Speed) | |||||
