Specifications
| Item Code | 212873 |
|---|---|
| Model | DKN612 |
| Circulation method | Forced air circulation |
| Operating temp. range | Room temp. +10°C to 250°C |
| Temp. adjustment accuracy | ±1℃（at 210℃） |
| Temp. distribution accuracy | ±2.5℃（at 210℃） |
| Max. temp. reaching time | Approx. 120 min. |
| Interior/Exterior material | Stainless steel / Cold rolled steel plate with melamine resin baking finish |
| Heat insulating material | Glass wool |
| Heater | Stainless pipe heater |
| Heater | 1.34 kW |
| Fan Type / Fan Motor | Scirocco fan, Condenser type motor |
| Cable hole | 30mm I.D. (on the right side) 1pc. |
| Exhaust port | 30mm I.D. x 2 (on top) |
| Observation window | 250×280mm Chemical strengthening glass x 3 |
| Temp. controller | PID control by microprocessor |
| Temp. setting method | Digital setting by UP/DOWN key |
| Temp. display | Measurement temp. : Digital display by green LED Setting temp. : Digital display by red LED |
| Timer | 1 min. to 99 Hrs. 59 min. and 100 Hrs. to 999 Hrs. 50 min. with timer wait function |
| Operation function | Fixed temperature operation, Program operation, Auto start, Quick Auto-stop |
| Program mode | Program operation : 30 steps (30 steps×1, 15 steps×2, 10 steps×3) Pattern repeat function |
| Additional functions | Calibration off-set function, Key lock, Uninterruptible power for memory |
| Heater circuit control | SSR control |
| Sensor | K-thermocouple |
| Safety device | Self diagnosis functions (temp. sensor abnormal, Heater disconnection, SSR- short, Automatic overheating prevention), Key lock function, Overheat prevention, Electric leakage breaker with over current protection |
| Shelf plate with standard load | ~15kg/piece |
| Shelf support step number/pitch | 13 steps / 30mm |
| Shelf plate | Stainless steel, 1pc on the bottom screwed |
| Shelf plate / support | 2 pcs. / 4 pcs. |
| Internal dimensions（W×D×H mm） | 600×500×500mm |
| External dimensions（W×D×H mm） | 710×651×870mm |
| Remarks(dimensions) | 150L |
| Power Source | AC220V 7A Single-phase |
| Weight | 65kg |
‘
‘
‘
